APP:Carecam PRO

(1) Dot matrix 10-light infrared, with USB interface (without network port), support for external plug-in 4G data card, mobile phone card, support for linkage alarm (smart home AIOT) expansion

(2) support for motion detection, cloud storage, TF card (128GB)

(3) Support AP hotspot, support ONVIF NVR protocol

(4) Support computer client

(5) Support human shape detection / tracking

(6) Mobile APP (Carecam / Carecam) Support 4 screens to watch simultaneously

(7) 5V2A power supply (packed with round tray bracket with power supply)

Specifications：

1. System	Main processor	FH8632V2
   	operating system	Embedded LINUX operating system
   Video	Image Sensor	1/2.7” 2 million pixels CMOS
   	Image coding standard	Smart H.264
   	Monitor image quality	1920 * 1080/640 * 360
   	Video quality	1920 * 1080
   	Image motion detection	stand by
   	Minimum illumination	0.1LUX / F1.2
   	Snapshot function	stand by
   	Video flip	stand by
   Audio	Coding standards	G.711 / G.726
   	Audio input	stand by
   	Audio output	stand by
   Video management	Cloud storage	Support (24/7 mobile monitoring)
   	Video mode	Manual recording, timing recording, alarm recording
   	Video save	TF card \ Computer \ Mobile
   	Remote playback	stand by
   	Alarm trigger	Video push, speaker alarm, alarm recording
   The internet	Wired network port	not support
   	wireless network	802.11b / g / n
   	Code stream	Dual stream
   	Network protocol	Support TCP / IP, RTSP, Onvif, etc.
   	WIFI networking	Scan code + AP distribution network
   Extension	IR-CUT	stand by
   	TF card	Supports up to 128GB TF card
   	WIFI	stand by
   	868 agreement	Support (optional)
   Powered by	power supply	DC 5V 2A
   	Power consumption	<10W
   Surroundings	Operating temperature	-10 ℃-+ 45 ℃
   	Working humidity	10% -90%
   Other	Lens	3.6MM HD lens
   	Light board	Infrared 10 lights (LED)
